Polyurethane & Mineral Wool Wall Panel System
Features + Benefits:
- Wall thickness range:40 -150mm
- Suitable to any construction style
- Can be installed and integrated with metal corrugated panel, decoration panel and stone
- Unique supporting system precisely calculated by engineers-simple but efficient
- Excellent sealing, moisture proof, airtight, heat insulation and sound insulation function
- Cost efficient with less and simple component, fast installation
Tech Data:
Beststeel IMP (Mineral Wool) Panel with ROCKWOOL mineral wool core, model 4″, is an insulated metal panel consisting of the face layer of steel facings having a PVDF coating, adhered to a 98.8 mm thick mineral wool core having a nominal density of 140 kg/m3. The nominal thickness of the panel is 100 mm and the maximum panel size is 1067 mm wide x 3050 mm high.
Beststeel IMP (Mineral Wool) panel wall assembly with steel purlins is a 100 mm thick non-loadbearing external wall assembly designed for fire exposure from one side only, and supported by the steel purlins located at the interior side of the wall panels.
FIRE RATINGS
| Test Standard | Rating | Design Number |
| CAN/ULC S101 ASTM E119 |
One hour non-loadbearing, interior exposure only |
IEP/IMP 60-01 |
